Glass Cloth Adhesive Tape With Easy-release Liner 160 Micron Thickness

Certificaat
CHINA UN.Tex (Dalian) Co.,Ltd certificaten
CHINA UN.Tex (Dalian) Co.,Ltd certificaten
Ik ben online Chatten Nu

Glass Cloth Adhesive Tape With Easy-release Liner 160 Micron Thickness

Glass Cloth Adhesive Tape With Easy-release Liner 160 Micron Thickness
Glass Cloth Adhesive Tape With Easy-release Liner 160 Micron Thickness Glass Cloth Adhesive Tape With Easy-release Liner 160 Micron Thickness Glass Cloth Adhesive Tape With Easy-release Liner 160 Micron Thickness Glass Cloth Adhesive Tape With Easy-release Liner 160 Micron Thickness

Grote Afbeelding :  Glass Cloth Adhesive Tape With Easy-release Liner 160 Micron Thickness

Productdetails:
Plaats van herkomst: China
Certificering: RoHS
Modelnummer: 652L
Betalen & Verzenden Algemene voorwaarden:
Min. bestelaantal: 500M2
Prijs: by quote
Verpakking Details: Elke kolom wordt verpakt en vervolgens in exportkarton.
Levertijd: 30 dagen
Betalingscondities: T/T, D/P, L/C
Levering vermogen: 10,000m2

Glass Cloth Adhesive Tape With Easy-release Liner 160 Micron Thickness

beschrijving
Steunmateriaal: E-vezel Glasdoek Rugdikte: 100UM
Totale dikte: 160um Kleefstoftype F-klasse: Acryl-drukgevoelig
Aansluiting op staal: ≥4N/10mm Treksterkte: ≥ 200N/10mm
Verlenging: ≥3% Afbrekingsspanning F-klasse: ≥1,8KV
Servicetemp.: -30°C ~ +150°C Tackrollende bal: ≤10cm
Snijrol: 10 mm ~ 500 mm breedte Rol lengte: 30m
Markeren:

glass cloth adhesive tape with liner

,

160 micron adhesive insulation tape

,

easy-release adhesive tape for insulation

Glass Cloth Adhesive Tape With Easy-release Liner 160 Micron Thickness
Product Overview
This glass cloth adhesive tape features a three-layer design with high-density glass cloth backing and strong acrylic adhesive, delivering durable bonding and reliable protection. The easy-release liner ensures smooth application for electrical insulation, mechanical fastening, and high-temperature protection applications.
Technical Specifications
Parameter Value
Total Thickness 160 Micron
Adhesion to Steel ≥ 4N/10mm
Tensile Strength ≥ 200N/10mm
Service Temperature -30°C ~ +150°C
Adhesive Type F-Class Acrylic Pressure-Sensitive
Key Advantages
  • Excellent Durability: Flexible, tear-resistant backing ensures reliable performance in demanding conditions.
  • Strong Adhesion: High-quality acrylic adhesive offers lasting bonds to various surfaces.
  • Wide Temperature Range & Protection: Operates from -30°C to 150°C with insulation, leak-proof, and heat-resistant properties.
Applications
  • Reliable Insulation & Fixation: Strong adhesion and high tensile strength make it ideal for wrapping and binding transformer and motor coils, providing secure insulation.
  • Battery Safety Protection: Explosion-proof and leak-resistant properties ensure effective insulation wrapping for high-energy lithium-ion batteries, enhancing pack safety.
  • High-Temperature & Surface Protection: Suitable for high-temperature sandblasting masking and shielding applications, protecting workpiece surfaces from damage.
Glass Cloth Adhesive Tape With Easy-release Liner 160 Micron Thickness 0
